3-way zone valve 3/4" IT V4044F1000
OEG no.: 512240001
Three-way zone valve with electric actuator for heating and cooling systems to control the flow of cold and hot water.
The valve is particularly suitable for systems with circulation pump and DHW...
Resideo 5-year warranty
CE
Three-way zone valve with electric actuator for heating and cooling systems to control the flow of cold and hot water.
The valve is particularly suitable for systems with circulation pump and DHW priority circuit where a pressure increase in the DHW system and in the pipe network of the heating system shall take place.
For more information see Downloads
| OEG no. | 512240001 |
| Connection size: | 3/4" IT |
| Voltage [V]: | 230 |
| Design: | Spring-loaded return |
| Auxiliary switch: | Yes |
| kvs-value [m³/h]: | 6.0 |
| Operating pressure max. [bar]: | 8.6 |
| Cable length: | 1 |
| Media temperature [°C]: | 5 .. 88 |
| Media: | Water |
| Power consumption [W]: | 5 .. 6 |
| Closing time [s]: | 30 |
| Manufacturer | Honeywell |
| Manufacturer number | V4044F1000 |
| Weight [kg] | 1.18 |
| Notes |
Resideo 5-year warranty
CE
|
| Customs tariff number | 84818059 |
Question
Bonjour, peut on trouver la même vanne avec un raccordemant 3/4 Male
Answer OEG:
la piece à l'identique avec un raccordement 3/4 male n'existe pas.
