6.5A power supply EPSITRON® COMPACT Power DC 12 V 07871021
OEG no.: 723000404
High-performance power supply unit for control panel installation on mounting rails. The power supply unit is suitable for series or parallel operation, is protected against idle running and short circuit,...
All product informationRelated products
EAC
CE
High-performance power supply unit for control panel installation on mounting rails. The power supply unit is suitable for series or parallel operation, is protected against idle running and short circuit, and the LED status display provides quick information about the operating status. CAGE CLAMP connection technology allows for a lightning-fast connection.
For more information see Downloads
| OEG no. | 723000404 |
| Current [A]: | 6.5 |
| Voltage secondary [V]: | 12 DC |
| Voltage primary [V]: | 100 .. 240 |
| Width x Height [mm]: | 90 x 89 |
| Output [W]: | 78 |
| Output voltage [V]: | 12 |
| Number of phases: | 1 |
| Efficiency [%]: | 87 |
| Type of connection: | Push-fit terminal |
| Depth [mm]: | 59 |
| Mounting type: | DIN-rail |
| Ambient temperature [°C]: | -25 .. 55 |
| Stripping length [mm]: | 6 .. 7 |
| Protection type [IP]: |
 IP20
|
| Manufacturer | Wago |
| Manufacturer number | 07871021 |
| EAN | 4050821498018 |
| Weight [kg] | 0.3 |
| Notes |
EAC
CE
|
| Customs tariff number | 85043121 |
