CeraMix Blue exposed shower mixer B9493AA
OEG no.: 800006154
Single-lever shower mixer for exposed installation. It is provided with IdealPure® nickel- and lead-free waterways. Thanks to insulated waterways, water and energy consumption are reduced. It is also...
All product information Scope of deliveryRelated products
certified by DVGW
Single-lever shower mixer for exposed installation. It is provided with IdealPure® nickel- and lead-free waterways. Thanks to insulated waterways, water and energy consumption are reduced. It is also equipped with an integrated hot water temperature limiter and ECO function.
| Scope of delivery: | |||
| 1 x | single-lever shower mixer | ||
| 1 x | Plastic rosette with wall sealing | ||
| 2 x | covered S-unions adjustable 137 - 167 mm | ||
| 1 x | CLICK cartridge ø 47 mm with ceramic sealing discs | ||
For more information see Downloads
| OEG no. | 800006154 |
| Application : | Shower |
| Fitting operation: | Single-lever mixer tap |
| Tap fitting installation: | 2-hole installation |
| Height of tap [mm]: | 122 |
| Width of mixer tap [mm]: | 220 |
| Depth of tap [mm]: | 143 |
| Waste set: | Without |
| Projection [mm]: | 143 |
| Flow rate [l/min]: | 28 |
| Operating pressure [bar]: | 3 |
| Inside micrometer [mm]: | 150 ± 13 |
| Connection size supply hose: | 1/2" IT |
| Cartridge: | Ø 47 mm CLICK cartridge |
| Installation opening [mm]: | Ø 70 |
| Design line: | CeraMix Blue |
| Application: | Cold and hot water |
| Type of connection: | High pressure |
| Mixer colour: | Chrome |
| Manufacturer | Ideal-Standard |
| Manufacturer number | B9493AA |
| EAN | 3800861022145 |
| Weight [kg] | 0.59 |
| Notes |
certified by DVGW
|
| Customs tariff number | 84818011 |
