1-pole circuit breaker with tripping characteristics C curve for automatic disconnection of electric circuits in case of a short circuit and for the protection of life-threatening situations caused by insulation faults or dangerous contact voltage.
There is also a disconnection when the wires are in danger due to high current load. Clear switch position indication by red/green marking on the switch.
With transparent window for inserting labels. Fixing by snap-in mechanism on the top-hat rail.
For more information see Downloads
| OEG no. | 711000470 |
| Trigger characteristic: | C |
| Residual current protection type: | A |
| Rated current [A]: | 16 |
| Rated residual current [A]: | 0.03 |
| Voltage [V]: | 230 |
| Number of poles: | 1 |
| Horizontal pitches [HP]: | 2 |
| Protection type [IP]: | 20 |
| Neutral conductor: | Yes |
| Type: | RCBO |
| Type: | DX3 |
| Protection type: |
 IP20
|
| Installation depth: | 44 |
| Ambient temperature [°C]: | -25 .. 60 |
| Manufacturer | Legrand |
| Manufacturer number | 411061 |
| EAN | 3245060085872 |
| Weight [kg] | 0.24 |
| Customs tariff number | 85362090 (FR) |
