Smart WiFi thermostat designed to replace conventional room thermostats. Temperature and time programmes can be conveniently set via the Intelliclima+ app. Alternatively, the temperature can be adjusted locally using the control knobs...
WiFi-capable
Smart WiFi thermostat designed to replace conventional room thermostats. Temperature and time programmes can be conveniently set via the Intelliclima+ app. Alternatively, the temperature can be adjusted locally using the control knobs. User behaviour is analysed to increase comfort and efficiency. Functions such as open-window detection and geolocation help to reduce energy consumption. With an additional power supply, the thermostat can be converted from battery operation to mains operation.
For more information see Downloads
| OEG no. | 211211482 |
| Power supply: | 2 x 1.5V AA battery |
| Switch contact: | 1 x changeover |
| Switching capacity [A]: | 5 (3) |
| Control range [°C]: | 2 .. 40 |
| Compatible with: | APP control, LoRa |
| Radio frequency: | 2.4 GHz |
| Length x Width x Height [mm]: | 98 x 20 x 98 |
| Protection type [IP]: |
 IP32
|
| Storage temperature [°C]: | -10 .. 60 |
| Ambient temperature [°C]: | 0 .. 45 |
| Type: | C900Q |
| Manufacturer | FantiniCosmi |
| Manufacturer number | C900Q |
| Weight [kg] | 0.2 |
| Notes |
WiFi-capable
|
| Customs tariff number | 90321020 |
Question
Hallo, Welchen Empfänger an dem die Stellmotoren angeschlossen werden kann ich für dieses Raumthermostat nehmen?
Answer OEG:
Es handelt sich nicht um eine Funk-Version. Der Thermostat wird normal verdrahtet, z.B. auf Terminal strip 230V for heating and cooling of up to 10 zones
