Installation cable for installation on or under the plaster, in dry, damp or wet interiors and in bricks and concrete. Direct embedding in vibrated or compressed concrete is not permitted...
Tutte le informazioni sul prodottoProdotti simili
VDE
EAC
CE
Installation cable for installation on or under the plaster, in dry, damp or wet interiors and in bricks and concrete. Direct embedding in vibrated or compressed concrete is not permitted.
Also suitable for outdoor use if protected against direct sunlight. The product complies with the 2006/95/EC guideline CE.
Technical data:
- rated voltage: 300 / 500 V
- test voltage: 2,000 V
- temperature range: during installation: 5° C ... 70° C,
fixed installation: -40° C ... 70° C
- bare copper conductor
- core insulation: PVC-based
- Core labelling according to DIN VDE 0293
- filling compound over the core assembly
| Codice OEG | 701001608 |
| UC | 50 m Ring |
| Quantità anime: | 5 |
| Sezione trasversale [mm²]: | 16 |
| DIN: | VDE 0293 |
| Contenuto di rame [kg/km]: | 768,0 |
| Wire identification: | NYM-J 5 x 16 |
| Tensione nominale [V]: | 300/500 |
| Tensione di prova [V]: | 2.000 |
| Isolamento: | PVC |
| Materiale: | Rame lucido |
| Range di temperatura flessibile [°C]: | 5 .. 70 |
| Range di temperatura fissa [°C]: | -40 .. 70 |
| Peso [kg] | 61 |
| Avvisi |
VDE
EAC
CE
|
| Codice doganale | 85444995 (EEC) |
Was kosten 15 M?
Guten Tag,
wir verkaufen den Ring nur im ganzen Stück.
Einzelne Meter können Sie bei uns nicht erwerben.
Mit freundlichen Grüßen
Das OEG TEAM
Per poter fare la domanda deve prima effettuare il login
07/08/16, 15:00:18 da: Signor Feld
gut
Eine sehr gute Mantelleitung NYM-J 5 x 16 mm²
