This OEG buffer storage tank fulfills the highest demands on heat storage, particularly where heat generators are used which achieve their optimal efficiency only under full load (e...
All product information Scope of delivery10-year warranty
High Quality
This OEG buffer storage tank fulfills the highest demands on heat storage, particularly where heat generators are used which achieve their optimal efficiency only under full load (e.g. many solid fuel boilers). During the operation of the heat generator, more heat is produced than the consumers can take. The excess heat heats the water of the buffer tank and is therefore stored. During later stand-still periods this heat can be retrieved, as needed.
The OEG buffer storage tank is suitable as a primary cylinder for solar systems, heat pumps, wood- or pellet boilers and can also be used in district heating systems. Due to the additional smooth-pipe exchanger, another heat generator can be integrated, and its energy can be fed into the buffer tank additionally.
Scope of delivery: | |||
1 x | buffer storage tank | ||
1 x | insulation |
For more information see Downloads
OEG no. | 516005382 |
Smooth-pipeheatexchanger: | 0 |
Installation type: | Vertical storage tank |
Manufacturer | OEG |
Notes |
10-year warranty High Quality |
Customs tariff number | 84191900 |
Rated volume according to EN 12897: | 2600 |
Colour: | silver |
Insulation according to DIN 4102-1 Fire Protection Class B2: | removable PES fleece insulation 0.036 W/(mK) |
Weight [kg]: | 310 |
Total height including insulation [mm]: | 2490 |
Diameter without insulation [mm]: | 1250 |
Diameter with insulation [mm]: | 1450 |
Tilt height [mm]: | 2530 |
pmax Tank [bar]: | 3 |
tmax Tank [°C]: | 95 |
tmin Tank [°C]: | 20 |
Connection layout: | 90° |
Connection sensor [Ø mm / terminal]: | 6 mm |
Connection heat generator [thread]: | Rp 1 1/2" |
Connection heating element [thread]: | Rp 1 1/2" |
Max. immersion depth of screw-in heater [mm]: | 1300 |
